Ricoh Aficio MP C3501

Fax Unit Options
SM 11 D393
Fax Option
Type C5000
(D393)
For D027/ D029
 The optional handset is available for the U.S. version only.
1. Remove the scanner left cover [A] ( x 2).
2. Make two holes in the scanner left cover.
 Drill a hole from the outside of the cover with a screwdriver.
3. Attach the hand set support bracket [C] inside the scanner left cover.
