Ricoh Aficio MP C3501 Service Manual

Error Codes
D393 32 SM
Code Meaning Suggested Cause/Action
during reception of
facsimile data
6-01
G3 ECM - no V.21 signal
was received
6-02
G3 ECM - EOR was
received
 Replace the FCU.
6-04
G3 ECM - RTC not
detected
 Check the line connection.
 Check for a bad line or defective remote
terminal.
 Replace the FCU.
6-05
G3 ECM - facsimile data
frame not received within
18 s of CFR, but there was
no line fail
 Check the line connection.
 Check for a bad line or defective remote
terminal.
 Replace the FCU.
 Try adjusting the rx cable equalizer
Cross reference
 Rx cable equalizer - G3 Switch 07 (PSTN)
6-06
G3 ECM - coding/decoding
error
 Defective FCU.
 The other terminal may be defective.
6-08
G3 ECM - PIP/PIN
received in reply to
PPS.NULL
 The other end pressed Stop during
communication.
 The other terminal may be defective.
6-09 G3 ECM - ERR received
 Check for a noisy line.
 Adjust the tx levels of the communicating
machines.
 See code 6-05.
6-10
G3 ECM - error frames still
received at the other end
after all communication
attempts at 2400 bps
 Check for line noise.
 Adjust the tx level (use NCU parameter 01 or
the dedicated tx parameter for that address).
 Check the line connection.
