Ricoh Aficio MP C3501 Service Manual

D086/D087 xiv SM
6.4.1 PAPER JAM DISPLAY .................................................................. 6-112
6.4.2 JAM CODES AND DISPLAY CODES ........................................... 6-113
Paper Size Code ............................................................................... 6-119
Sensor Locations .............................................................................. 6-120
6.5ELECTRICAL COMPONENT DEFECTS ................................................ 6-121
6.5.1 SENSORS ..................................................................................... 6-121
6.5.2 BLOWN FUSE CONDITIONS........................................................ 6-127
Power Supply Unit ............................................................................. 6-127
IH Inverter ......................................................................................... 6-128
6.6SCANNER TEST MODE ........................................................................ 6-129
6.6.1 SBU TEST MODE ......................................................................... 6-129
ENERGY SAVING
7. ENERGY SAVING ........................................................................ 7-1
7.1ENERGY SAVE .......................................................................................... 7-1
7.1.1 ENERGY SAVER MODES ................................................................ 7-1
Timer Settings ....................................................................................... 7-1
Return to Stand-by Mode ...................................................................... 7-2
Recommendation .................................................................................. 7-2
7.1.2 ENERGY SAVE EFFECTIVENESS ................................................... 7-3
7.2PAPER SAVE ............................................................................................. 7-5
7.2.1 EFFECTIVENESS OF DUPLEX/COMBINE FUNCTION ................... 7-5
1. Duplex: .............................................................................................. 7-5
2. Combine mode: ................................................................................. 7-5
3. Duplex + Combine: ........................................................................... 7-5
How to calculate the paper reduction ratio ............................................ 7-6
D088/D089 SERVICE MANUAL APPENDICES
SEE D088/D089 SERVICE MANUAL APPENDICES SECTION FOR DETAILED TABLE OF
CONTENTS
1000-SHEET FINISHER (B408)
SEE SECTION B408 FOR DETAILED TABLE OF CONTENTS

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
