Ricoh Aficio MP C3501 Service Manual

Main SP Tables-1
D086/D087 5-24 SM
003 Low :1st CPM *ENG
[10 to 100 / 80 / 5 %/step]
Specifies the 1st CPM down ration against the normal CPM in the low
temperature condition.
004 Low :2nd CPM *ENG
[10 to 100 / 65 / 5 %/step]
Specifies the 2nd CPM down ration against the normal CPM in the low
temperature condition.
005 Low :3rd CPM *ENG
[10 to 100 / 50 / 5 %/step]
Specifies the 3rd CPM down ration against the normal CPM in the low
temperature condition.
006 High :1st CPM *ENG
[10 to 100 / 75 / 5 %/step]
Specifies the 1st CPM down ration against the normal CPM in the high
temperature condition.
007 High:2nd CPM *ENG
[10 to 100 / 50 / 5 %/step]
Specifies the 3rd CPM down ration against the normal CPM in the high
temperature condition.
008 High:3rd CPM *ENG
[10 to 100 / 25 / 5 %/step]
Specifies the 1st CPM down ration against the normal CPM in the high
temperature condition.
009
High:1st CPM Down
Temp.:A3
*ENG
[100 to 250 / 230 / 1 deg/step]
Specifies the heating roller temperature for 1st CPM down of A3 paper size.
010
High:2nd CPM Down
Temp.:A3
*ENG
[100 to 250 / 233 / 1 deg/step]
Specifies the heating roller temperature for 2nd CPM down of A3 paper size.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
