Main SP Tables-2
SM 5-49 D086/D087
System
Maintenance
2111 [Forced Line Position Adj.]
001 Mode a -
Executes the fine line position adjustment
twice.
If this SP is not completed (NG is
displayed), do SP2111-003 first and then try
this SP again.
002 Mode b -
Executes the fine line position adjustment
once.
If this SP is not completed, do SP2111-003
first and then try this SP again.
003 Mode c -
Executes the rough line position adjustment
once.
After doing this SP, make sure to execute
SP2111-001 or -002. Otherwise, the line
position adjustment is not perfectly done.
2112
[TM/ID Sensor Check] ID Sensor Check FA
001 Execute
[0 or 1 / 0 / 1 /step]
This SP is used to check the ID sensors at
the factory. The results of this SP are
displayed in SP2140 to SP2145.
2117
[Skew Adjustment]
Specifies a skew adjustment value for the skew motor M, C or Y.
These SPs must be used when a new laser optics housing unit is installed or
when SC2.585 occurs. For details, see "Laser Optics Housing Unit" in the
"Replacement and Adjustment" section.
001 Pulse: M *ENG
[–50 to 50 / 0 / 1 pulse/step]
002 Pulse: C *ENG
003 Pulse: Y *ENG
