Main SP Tables-2
D086/D087 5-50 SM
2118 [Skew Adjustment]
001 Execute: M *ENG Changes the current skew adjustment
values to the values specified with SP2117.
These SPs must be used when a new laser
optics housing unit is installed or when
SC2.585 occurs. For details, see "Laser
Optics Housing Unit" in the "Replacement
and Adjustment" section.
002 Execute: C *ENG
003 Execute: Y *ENG
2119
[Skew Adjustment Display]
Displays the current skew adjustment value for each skew motor.
001 M *ENG
[–50 to 50 / 0 / 1 pulse/step]
002 C *ENG
003 Y *ENG
2150
[Area Mag. Correction] LD Pulse Area Correction (Color, Area) FA
Adjusts the magnification for each area. The main scan (297 mm) is divided
into 8 areas. Area 1 is at the front side of the machine (left side of the image)
and area 8 is at the rear side of the machine (right side of the image).
Decreasing a value makes the image shift to the left side on the print.
Increasing a value makes the image shift to the right side on the print.
1 pulse = 1/16 dot
027 Area 0: Bk *ENG
[-256 to 255 / 0 / 1sub-dot/step]
028 Area 1: Bk *ENG
Adjusts the area magnification for LD 0.
[–256 to 255 / 0 / 1 sub-dot/step ]
029 Area 2: Bk *ENG
030 Area 3: Bk *ENG
031 Area 4: Bk *ENG
032 Area 5: Bk *ENG
033 Area 6: Bk *ENG
