Ricoh Aficio MP C3501 Service Manual

System SP1-xxx
D086/D087 3-2 SM Appendix
020 By-pass: Plain:1200 *ENG
021 By-pass: Middle Thick:1200 *ENG
022 By-pass: Thick 1:1200 *ENG
023 Duplex: Plain:1200 *ENG
024 Duplex: Middle Thick:1200 *ENG
025 Duplex: Thick 1:1200 *ENG
1002
[Side to Side Reg.] Side-to-Side Registration Adjustment
Adjusts the side-to-side registration by changing the laser main scan start
position for each mode.
001 By-pass Table *ENG
[–4 to 4 / 0.0 / 0.1 mm/step]
002 Paper Tray 1 *ENG
003 Paper Tray 2 *ENG
004 Paper Tray 3 *ENG
005 Paper Tray 4 *ENG
006 Duplex *ENG
007 Paper Tray 5 *ENG
008 Large Capacity Tray *ENG
1003
[Paper Buckle] Paper Buckle Adjustment
(Tray Location, Paper Type), Paper Type: N: Normal, TH: Thick
Adjusts the amount of paper buckle at the registration roller by changing the
paper feed timing.
002 Paper Tray1: Plain *ENG
[–9 to 5 / -2 / 1 mm/step]
003 Tray1: Middle Thick *ENG
[–9 to 5 / -1 / 1 mm/step]
004 Paper Tray1: Thick1 *ENG
[–9 to 5 / -2 / 1 mm/step]
007 Paper Tray2/3/4/5/LCT: Plain *ENG

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
