HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 370
Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
Adeos II
Adeos2.mcs
I: 30 Mbps
Q: 30 Mbps
UQPSK: 6dB
(or ¼
AUSQPSK)
NRZ-M
OFF
I channel A
Q channel B
5
AKARI
Akari.mcs
8.388608 Mbps
QPSK
NRZ-M
Dual
Normal
3
Alos
Alos.mcs
138.76 Mbps
QPSK
DNRZ
OFF
Merge
3
Alsat
Alsat2.mcs
65 Mbps
8PSK
TCM 2.00/3
OFF
Merge
1
Aqua DB
AquaDB.mcs
15 Mbps
OQPSK
NRZ-M
OFF
Merge
3
Aqua DP
AquaDP.mcs
150 Mbps
OQPSK
NRZ-M
OFF
Merge
3
Aqua DP & DB
AquaDP_DB.mcs
15 Mbps
150 Mbps
OQPSK
NRZ-M
OFF
Merge
3
ATV
ATV.mcs
6 Mbps
OQPSK
NRZ-M
OFF
Merge
3
Aura DP & DB
AuraDP_DB.mcs
15 Mbps
150 Mbps
OQPSK
NRZ-M
OFF
Merge
3
CBERS
CBERS.mcs
53 Mbps
QPSK
DNRZ
OFF
Normal
3
Corriolis 1
Corriolis1.mcs
51.2 Mbps
OQPSK
NRZ-M
OFF
Merge
3
