HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 371
Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
Corriolis 2
Corriolis2.mcs
Corriolis2_FS.mcs
102.4 Mbps
OQPSK
NRZ-M
Dual
Merge
3
Cosmo
Cosmo.mcs
155 Mbps
QPSK
DNRZ
OFF
Normal
3
Cryosat
Cryosat.mcs
100 Mbps
QPSK
DNRZ
OFF
Normal
3
Demeter
Demeter.mcs
16 Mbps
8PSK
TCM 2.00/3
OFF
Merge
1
Envisat
Envisat_Asar.mcs
100 Mbps
QPSK
DNRZ
OFF
Merge
3
Envisat
Envisat_Meris.mcs
100 Mbps
QPSK
DNRZ
OFF
Normal
3
Envisat
Envisat_Meris_Asar.mcs
100 Mbps
QPSK
DNRZ
OFF
Merge
3
EO1
EO1merge.mcs
EO1nonmerge.mcs
EO1merge_nomerge.mcs
105 Mbps
QPSK
DNRZ
OFF
Merge or
Normal
or Both
depend on
mcs file
3
EROS
EROS.mcs
87.5 Mbps
QPSK
DNRZ
OFF
Merge
3
ERS-1
ERS1merge.mcs
& ERS1nonmerge.mcs
105 Mbps
QPSK
DNRZ
OFF
Merge or
normal depend
on mode
3
