HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 373
Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
IRS-1C
IRS-1C_pan.mcs
84.903 Mbps
QPSK
DNRZ
OFF
Merge
3
IRS-1D
IRS-1D_liss3.mcs
42.4515 Mbps
QPSK
DNRZ
OFF
Normal
3
IRS-1D
IRS-1D_pan.mcs
84.903 Mbps
QPSK
DNRZ
OFF
Normal
3
IRSP4
IRSP4.mcs
20.8 Mbps
QPSK
DNRZ
OFF
Normal
3
IRSP5
IRSP5.mcs
84.903 Mbps
QPSK
DNRZ
OFF
Normal
3
IRSP6
IRSP6.mcs
105 Mbps
QPSK
DNRZ
OFF
Normal
3
JEM
JEM.mcs
100 Mbps
QPSK
NRZ-M
Single
Merge
3
JEM FORWARD
JEMFordward.mcs
6 Mbps
BPSK
NRZ-M
ON
Normal
3
Kompsat-2
Kompsat2.mcs
320 Mbps
OQPSK
NRZ-M
OFF
Merge
3
Landsat-5
Landsat5.mcs
I: 84.09 Mbps
Q: 15.06 Mbps
UQPSK: 6dB
NRZ-M
OFF
I channel A
Q channel B
5
Landsat-7
Landsat7.mcs
Landsat7_FS.mcs
I: 74.914 Mbps
Q: 74.914 Mbps
UQPSK: 0dB
(AQPSK)
NRZ-L
OFF
I channel A
Q channel B
5
