Safran CORTEX Series - Page 374

HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 374
Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
LRO HR MR
LRO_High_Medium.mcs
75 Mbps
50 Mbps
OQPSK
NRZ-M
Dual
Merge
3
LRO MR LR
LRO_Medium_Low.mcs
50 Mbps
25 Mbps
OQPSK
NRZ-M
Dual
Merge
3
Metop
Metop.mcs
Metop_FS.mcs
70 Mbps
QPSK
NRZ-L
OFF
Merge
3
Metop HRPT
Metop_HRPT_FS.mcs
4.6666 Mbps
QPSK
NRZ-L
Single
Normal
3
NPOES
NPOES.mcs
NPOES_FS.mcs
300 Mbps
OQPSK
NRZ-M
OFF
Merge
3
NPP
NPP.mcs
NPP_FS.mcs
300 Mbps
OQPSK
NRZ-M
OFF
Merge
3
NRL-1
NRL1.mcs
51.2 Mbps
OQPSK
NRZ-M
OFF
Merge
3
NRL-2
NRL2.mcs
102.4 Mbps
OQPSK
NRZ-M
Dual
Merge
3
OFEC
OFEC.mcs
103 Mbps
QPSK
DNRZ
OFF
Merge
3
Oryx
Oryx.mcs
125.414 Mbps
QPSK
NRZ-M
Dual
Normal
3
