HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 376
Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
SICH BPSK LR
SICH-BPSK-LR.mcs
15.36 Mbps
BPSK
NRZ-M
OFF
Normal
3
SPOT-2
SPOT2.mcs
49.372 Mbps
QPSK
DNRZ
OFF
Merge
3
SPOT-4
SPOT4.mcs
49.372 Mbps
QPSK
DNRZ
OFF
Merge
3
SPOT-5
spot5.mcs
spot5_FS.mcs
49.372 Mbps
QPSK
DNRZ
OFF
Merge
3
SPOT VGT L band
SPOT_VGT_LBand.mcs
1.0204 Mbps
BPSK
NRZ-M
ON
Normal
3
SPOT VGT X band
SPOT_VGT_Band.mcs
3.4021 Mbps
BPSK
NRZ-M
OFF
Normal
3
SSTL BPSK
SSTL-Bpsk.mcs
40 Mbps
BPSK
NRZ-M
OFF
Merge
3
SSTL QPSK
SSTL-Qpsk.mcs
80 Mbps
QPSK
NRZ-M
Single
Normal
3
Terra
Terra.mcs
Terra_FS.mcs
I: 26.250 Mbps
Q: 13.125 Mbps
UQPSK: 6dB
(or ¼
AUSQPSK)
NRZ-M
I: ON
Q: OFF
I channel A
Q channel B
MODIS is on
channel A:
data1 + CLK
5
