Satellite
+ MCS Document
to be loaded
Bit rate
Modulation
Viterbi
Mode
Output mode
Basic
Menu
Terra High Rate
Terra_highdatarate.mcs
150 Mbps
OQPSK
NRZ-M
I: 8 // decod.
Q: 8 //
decod.
Merge
7
TerraSARX
TerraSARX.mcs
300 Mbps
QPSK
DNRZ
OFF
Merge
3
TopSat BPSK
TopSat-BPSK.mcs
11.052 Mbps
BPSK
NRZ-M
ON
Normal
3
TopSat QPSK
TopSat-BPSK.mcs
22.104 Mbps
QPSK
NRZ-M
Dual
Normal
3
Worldview 2
Worldview2.mcs
400 Mbps
OQPSK
NRZ-M
DEAF
OFF
Merge
3
