Creating a ShopTurn program
7.18 Example: Standard machining
Turning
260 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
XRA 2inc
ZRA 5inc
Tool change point Machine
XT 160abs
ZT 409abs
SC 1
S1 4000rev/min
Machining direction Climbing
2. Press the "Accept" softkey.
The work plan is displayed. Program header and end of program are
created as program blocks.
The end of program is automatically defined.
2. Stock removal cycle for facing
1. Press the "Turning" and "Stock removal" softkeys.
2. Select the machining strategy.
3. Enter the following technology parameters:
T Roughing
tool_80
D1 F 0.300 mm/rev V 350 m/min
4. Enter the following parameters:
Machining Roughing (∇)
Position
Direction Face (parallel to the X axis)
X0 90abs
Z0 2abs
X1 -1.6abs
Z1 0abs
D 2inc
UX 0inc
UZ 0.1inc
5. Press the "Accept" softkey.
