Creating a ShopTurn program
7.18 Example: Standard machining
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
261
3. Input of blank contour with contour computer
1. Press the "Cont. turn." and "New contour" softkeys.
The "New Contour" input window opens.
2. Enter the contour name (in this case: Cont_1).
The contour calculated as NC code is written as internal subprogram
between a start and an end marker containing the entered name.
3. Press the "Accept" softkey.
The "Starting point" entry field opens.
4. Enter the starting point of the contour.
X 60abs Z 0abs
5. Press the "Accept" softkey.
6. Enter the following contour elements and acknowledge using the
"Accept" softkey.
6.1 Z -40abs
6.2 X 80abs Z -45abs
6.3 Z -65abs
6.4 X 90abs Z -70abs
6.5 Z -95abs
6.6 X 0abs
6.7 Z 0abs
6.8 X 60abs Z 0abs
