Creating a ShopTurn program
7.18 Example: Standard machining
Turning
268 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
9. Groove (finishing)
1. Press the "Turning", "Groove" and "Groove with inclines" softkeys.
The "Groove 2" entry field opens.
2. Enter the following technology parameters:
T Grooving tool D1 F 0.1 mm/rev V 220 m/min
3. Enter the following parameters:
Machining Finishing (∇∇∇)
Groove position
Reference point
X0 60abs
Z0 -70
B1 5.856inc
T1 4inc
α1 15Degrees
α2 15Degrees
FS1 1
R2 1
R3 1
FS4 1
N 1
4. Press the "Accept" softkey.
10. Longitudinal threads M48 x2 (roughing)
1. Press the "Turning", "Thread" and "Thread longitudinal" softkeys.
The "Longitudinal thread" entry field opens.
2. Enter the following parameters:
T Threading tool_2 D1
Table without
