Creating a ShopTurn program
7.18 Example: Standard machining
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
269
P 2mm/rev
G 0
S 995rev/min
Machining type Roughing (∇)
Infeed: Constant cutting
cross-section
Diminishing
Thread External thread
X0 48abs
Z0 0abs
Z1 -25abs
LW 4inc
LR 4inc
H1 1.227inc
αP 30Degrees
Infeed
ND 5
U 0.150inc
VR 1inc
Multiple threads No
α0 0Degrees
3. Press the "Accept" softkey.
11. Longitudinal threads M48 x 2 (finishing)
1. Press the "Turning", "Thread" and "Thread longitudinal" softkeys.
The "Longitudinal thread" entry field opens.
2. Enter the following parameters:
T Threading tool_2 D1
Table without
P 2mm/rev
G 0
S 995rev/min
Machining type Finishing (∇∇∇)
Thread External thread
X0 48abs
