Siemens SINUMERIK 828D Turning User Manual

Programming technology functions (cycles)
8.1 Drilling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
287
3. Press the softkeys "Drilling Reaming" and "Boring" for ShopTurn
The "Boring" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
RP Retraction plane mm D Cutting edge number
SC Safety clearance mm F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description Unit
Machining
position
(only for G code)
• Single position
Drill hole at programmed position.
• Position pattern
Position with MCALL
DIR
(only for G code)
Direction of rotation
•
•
Z0 (only for G
code)
Reference point Z mm
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
