Programming technology functions (cycles)
8.1 Drilling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
305
Parameter Description Unit
LAB
(only for G code)
Repeat jump label for position
PL
(only for G code)
Machining plane
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
Coordinate
system
(only for
ShopTurn)
• right-angled or polar
Dimensions in right-angled coordinates or polar coordinates (only for face C and
face Y)
• right-angled or cylindrical
Dimensions in right-angled coordinates or cylindrical coordinates - (only for
peripheral surface C)
X0
Y0
X1
...X8
Y1
...Y8
(only for G code)
X coordinate of 1st position (abs)
Y coordinate of 1st position (abs)
X coordinate for additional positions (abs or inc)
Y coordinate for additional positions (abs or inc)
mm
mm
mm
mm
Z0
CP
X0
Y0
X1
... X7
Y1
... Y7
(only for
ShopTurn)
Face C and face Y - at right angles:
Z coordinate of the reference point (abs)
Positioning angle for machining area (only for face Y)
X coordinate of 1st position (abs)
Y coordinate of 1st position (abs)
X coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated.
Y coordinate for additional positions (abs or inc)
Incremental dimension: The sign is also evaluated.
mm
Degrees
mm
mm
mm
mm
