Programming technology functions (cycles)
8.1 Drilling
Turning
312 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
X0
Z0
α0
α1
N
only for
ShopTurn)
Peripheral surface C:
Cylinder diameter ∅ (abs)
Z coordinate of the reference point (abs)
Starting angle for first position referred to the Y axis.
Positive angle: Circle is rotated counterclockwise.
Negative angle: Circle is rotated clockwise.
Advance angle - (for pitch circle only)
Number of positions
mm
mm
Degrees
Degrees
X0
C0
Y0
Z0
α0
α1
N
R
Positioning
(only for
ShopTurn)
Peripheral surface Y:
X coordinate of the reference point (abs)
Positioning angle for machining surface
Y coordinate of the reference point (abs)
Z coordinate of the reference point (abs)
Starting angle for first position referred to the Y axis.
Positive angle: Circle is rotated counterclockwise.
Negative angle: Circle is rotated clockwise.
Advance angle - (for pitch circle only)
Number of positions
Radius
• Straight line: Next position is approached linearly in rapid traverse.
• Circular: Next position is approached along a circular path at the feedrate defined in
the machine data.
mm
Degrees
mm
mm
Degrees
Degrees
mm
