Introduction
1.2 Operator panel fronts
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
33
<Minus>
• Closes a directory which contains the element.
• Reduces the size of the graphic view for simulation and traces.
<Equals>
Opens the calculator in the entry fields.
<Asterisk>
Opens a directory with all of the subdirectories.
a
<Tilde>
Changes the sign of a number between plus and minus.
<INSERT>
• Opens an editing window in the insert mode. Pressing the key
again, exits the window and the entries are undone.
• Opens a selection box and shows the selection possibilities.
• In the machining step program, enters an empty line for G code.
• Changes into the double editor or into the multi-channel view
from the edit mode into the operating mode. You can return to
the edit mode by pressing the key again.
+
<INSERT> + <SHIFT>
For G code programming, for a cycle call activates or deactivates
the edit mode.
<INPUT>
• Completes input of a value in the entry field.
• Opens a directory or a program.
• Inserts an empty program block if the cursor is positioned at the
end of a program block.
• Inserts a character to select a new line and the program block is
split up into two parts.
• In the G code, inserts a new line after the program block.
• In the machining step program, inserts a new line for G code e
• Changes into the double editor or into the multi-channel view
from the edit mode into the operating mode. You can return to
the edit mode by pressing the key again.
<ALARM> - only OP 010 and OP 010C
Calls the "Diagnosis" operating area.
<PROGRAM> - only OP 010 and OP 010C
Calls the "Program Manager" operating area.
