Programming technology functions (cycles)
8.3 Contour turning
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
363
Parameters, G code program Parameters, ShopTurn program
PRG Name of the program to be generated T Tool name
PL Machining plane D Cutting edge number
RP Retraction plane mm F Feedrate mm/rev
SC Safety clearance mm S / V
Spindle speed or constant cutting
rate
rpm
m/min
F Feedrate *
CON Name of the updated blank contour for
residual material machining (without the
attached character "_C" and double-
digit number)
Residual
material
With subsequent residual material
removal
• Yes
• No
CONR Name to save the updated unmachined-
part contour for residual material
removal - (only "Yes" for residual
material removal)
Parameters Description Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• Face
• Longitudinal
• Parallel to the contour
• From inside to outside
• From outside to inside
• From end face to rear side
• From rear side to end face
Machining
direction
The machining direction depends on the stock removal direction and choice of tool.
Position
• front
• back
• internal
• external
D Maximum depth infeed - (only for ∇) mm
XDA 1. Grooving limit tool (abs) – (only for face machining direction) mm
XDB 2. Grooving limit tool (abs) – (only for face machining direction) mm
DX Maximum depth infeed - (only for parallel to the contour, as an alternative to D) mm
Do not round contour at end of cut.
Always round contour at end of cut.
