Programming technology functions (cycles)
8.4 Milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
379
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Face milling" softkey.
The "Face Milling" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL
Machining plane T Tool name
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate *
parameters Description Unit
Machining surface
(only for
ShopTurn)
• Face Y
• Peripheral surface Y
(only for
ShopTurn)
Clamp/release spindle
The function must be set up by the machine manufacturer.
Machining
The following machining technologies can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
Direction
Same direction of machining
•
•
Alternating direction of machining
•
•
