Programming technology functions (cycles)
8.4 Milling
Turning
380 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
parameters Description Unit
(only for G code)
X0
Y0
Z0
X1
Y1
Z1
The positions refer to the reference point:
Corner point 1 in X
Corner point 1 in Y
Height of blank
Corner point 2X (abs) or corner point 2X in relation to X0 (inc)
Corner point 2Y (abs) or corner point 2Y in relation to Y0 (inc)
Height of blank (abs) or height of blank in relation to Z0 (inc)
mm
mm
mm
mm
mm
mm
(only ShopTurn)
CP
X0
Y0
Z0
X1
Y1
Z1
Face Y: The positions refer to the reference point:
Positioning angle for machining area - only for face Y
Corner point 1 in X
Corner point 1 in Y
Height of blank
Corner point 2 in X (abs) or corner point 2X in relation to X0 (inc)
Corner point 2 in Y (abs) or corner point 2Y in relation to Y0 (inc)
Height of blank (abs) or height of blank in relation to Z0 (inc)
Degrees
mm
mm
mm
mm
mm
mm
(only ShopTurn)
C0
Y0
Z0
X0
Y1
Z1
X1
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining area - (only for peripheral surface Y)
Corner point 1 in Y
Corner point 1 in Z
Height of blank
Corner point 2 in Y (abs) or corner point 2X in relation to Y0 (inc)
Corner point 2 in Z (abs) or corner point 2Y in relation to Z0 (inc)
Height of blank (abs) or height of blank in relation to X0 (inc)
Degrees
mm
mm
mm
mm
mm
mm
DXY Maximum plane infeed
Alternately, you can specify the plane infeed in %, as a ratio → plane infeed (mm) to
milling cutter diameter (mm).
mm
%
DZ Maximum depth infeed – (for roughing only) mm
UZ Finishing allowance, depth mm
* Unit of feedrate as programmed before the cycle call
Note
The same finishing allowance must be entered for both roughing and finishing. The finishing
allowance is used to position the tool for retraction.
