Programming technology functions (cycles)
8.4 Milling
Turning
384 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for
ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
The following machining operations can be selected:
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇∇∇ edge (edge finishing)
• Chamfering
Machining
position
• Single position
Mill rectangular pocket at the programmed position (X0, Y0, Z0).
• Position pattern
Position with MCALL
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for
ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or
degrees
mm
mm
