Programming technology functions (cycles)
8.4 Milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
385
Parameter Description Unit
C0
Y0
Z0
X0
(only for
ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
W Pocket width mm
L Pocket length mm
R Corner radius mm
α0 Angle of rotation Degrees
Z1
Pocket depth (abs) or depth relative to Z0 (inc) – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UXY Plane finishing allowance – (only for ∇, ∇∇∇ or ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇, ∇∇∇) mm
Insertion
The following insertion modes can be selected – (only for ∇, ∇∇∇ or ∇∇∇ edge):
• Predrilled: (only for G code)
With G0, the pocket center point is approached at the retraction plane level, and
then, from this position, also with G0, the axis travels to the reference point brought
forward by the safety clearance. The machining of the rectangular pocket is then
performed according to the selected insertion strategy, taking into account the
programmed blank dimensions.
• Vertical: Insert vertically at center of pocket
The tool executes the calculated actual depth infeed at the pocket center in a single
block. This setting can be used only if the cutter can cut across center or if the
pocket has been predrilled.
• Helical: Insert along helical path
The cutter center point traverses along the helical path determined by the radius
and depth per revolution (helical path). If the depth for one infeed has been
reached, a full circle motion is executed to eliminate the inclined insertion path.
• Oscillating: Insert with oscillation along center axis of rectangular pocket(only for G
code)
The cutter center point oscillates back and forth along a linear path until it reaches
the depth infeed. When the depth has been reached, the path is traversed again
without depth infeed in order to eliminate the inclined insertion path.
