Programming technology functions (cycles)
8.4 Milling
Turning
390 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters, G code program Parameters, ShopTurn program
PL Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate *
Parameter Description Unit
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
• Peripheral surface C
• Peripheral surface Y
Position
(only for
ShopTurn)
• At the front (face)
• At the rear (face)
• Outside (peripheral surface)
• Inside (peripheral surface)
(only for
ShopTurn)
Clamp/release spindle (only for end face Y/peripheral surface Y)
The function must be set up by the machine manufacturer.
Machining
• ∇ (roughing, plane-by-plane or helical)
• ∇∇∇ (finishing, plane-by-plane or helical)
• ∇∇∇ edge (edge finishing, plane-by-plane or helical)
• Chamfering
Machining type
• Plane by plane
Solid machine circular pocket plane-by-plane
• Helical
Solid machine circular pocket helically
Machining
position
• Single position
A circular pocket is machined at the programmed position (X0, Y0, Z0).
• Position pattern
Several circular pockets are machined in a position pattern
(e.g. full circle, pitch circle, grid, etc.).
