Programming technology functions (cycles)
8.4 Milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
391
Parameter Description Unit
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for
ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only for
ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
∅ Diameter of pocket mm
Z1
Pocket depth (abs) or depth relative to Z0/X0 (inc) – (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇ and ∇∇∇)
in
%
DZ Maximum depth infeed - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇ and ∇∇∇) mm
