Programming technology functions (cycles)
8.4 Milling
Turning
402 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Multi-edge spigot" and "Multi-edge" softkeys.
The "Multi-edge" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL
Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate *
Parameter Description Unit
Machining
surface
(only for
ShopTurn)
• Face C
• Face Y
Position
(only for
ShopTurn)
• Front
• back
(only for
ShopTurn)
Clamp/release spindle (only for face Y)
The function must be set up by the machine manufacturer.
