Programming technology functions (cycles)
8.4 Milling
Turning
406 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Note
The following error messages can occur when chamfering inside contours:
• Safety clearance in the program header too large
This error message appears when chamfering would, in principle, be possible with the
parameters entered for FS and ZFS, but the safety clearance then could not be
maintained.
• Immersion depth too large
This error message appears when chamfering would be possible through the
reduction of the immersion depth ZFS.
• Tool diameter too large
This error message appears when the tool would already damage the edges during
insertion. In this case, the chamfer FS must be reduced.
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Press the "Milling" softkey.
3. Press the "Groove" and "Longitudinal groove" softkeys.
The "Longitudinal Groove (SLOT1)" input window opens.
Parameters, G code program Parameters, ShopTurn program
PL
Machining plane T Tool name
Milling direction D Cutting edge number
RP Retraction plane mm F
Feedrate mm/min
mm/tooth
SC Safety clearance mm S / V
Spindle speed or constant
cutting rate
rpm
m/min
F Feedrate *
