Programming technology functions (cycles)
8.4 Milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
413
Parameter Description Unit
Machining
• ∇ (roughing)
• ∇∇∇ (finishing)
• ∇∇∇ edge (edge finishing)
• Chamfering
FZ (only for G
code)
Depth infeed rate *
Circular pattern
• Full circle
The circumferential slots are positioned around a full circle. The distance from one
circumferential slot to the next circumferential slot is always the same and is
calculated by the control.
• Pitch circle
The circumferential slots are positioned around a pitch circle. The distance from
one circumferential slot to the next circumferential slot can be defined using angle
α2.
X0
Y0
Z0
(only for G code)
The positions refer to the reference point:
Reference point X – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
mm
mm
mm
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face C: The positions refer to the reference point:
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar – (only for single position)
Reference point Z – (only for single position)
mm
mm or
degrees
mm
CP
X0 or L0
Y0 or C0
Z0
(only for
ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area – (only single position)
Reference point X or reference point length polar – (only for single position)
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only for
ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar - (only for single position)
Reference point Z - (only for single position)
Cylinder diameter ∅ – (only for single position)
mm or
degrees
mm
mm
