Programming technology functions (cycles)
8.4 Milling
Turning
414 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
C0
Y0
Z0
X0
(only for
ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
N Number of slots
R Radius of circumferential slot mm
α0 Starting angle Degrees
α1 Opening angle of the slot Degrees
α2 Advance angle - (for pitch circle only) Degrees
W Slot width mm
Z1 Slot depth (abs) or depth relative to Z0 or X0 (inc) - (only for ∇, ∇∇∇) mm
DZ Maximum depth infeed - (only for ∇, ∇∇∇ ) mm
UXY Plane finishing allowance – (only for ∇, ∇∇∇) mm
Positioning
Positioning motion between the slots:
• Straight line:
Next position is approached linearly in rapid traverse.
• Circular:
Next position is approached along a circular path at the feedrate
defined in a machine data code.
FS Chamfer width for chamfering (inc) - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
