Programming technology functions (cycles)
8.4 Milling
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
423
Parameter Description Unit
C0
Y0
Z0
X0
(only for
ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y – (only for single position)
Reference point Z – (only for single position)
Reference point X – (only for single position)
Degrees
mm
mm
mm
W Slot width mm
L Slot length mm
α0 Angle of rotation of slot Degrees
Z1
(only for G code)
Slot depth (abs) or depth relative to Z0 (abs) – (only for ∇, ∇∇∇, ∇∇∇ base and ∇∇) mm
Z1 or X1
(only for
ShopTurn)
Slot depth (abs) or depth relative to Z0 or X0 (abs) – (only for ∇, ∇∇∇, ∇∇∇ base and
∇∇)
(Z1 for machining surface, face C/Y or X1 for peripheral surface C/Y)
mm
DXY
• Maximum plane infeed
• Maximum plane infeed as a percentage of the milling cutter diameter
- (only for ∇)
mm
%
DZ Maximum depth infeed - (only for ∇, ∇∇, ∇∇∇ and ∇∇∇ edge)
- (only for vortex milling)
mm
UXY Plane finishing allowance (slot edge) - (only for ∇, ∇∇ and ∇∇∇ base) mm
UZ Depth finishing allowance (slot base) - (only for ∇, ∇∇ and ∇∇∇ edge) mm
FZ Chamfer width for chamfering (inc) - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
* Unit of feedrate as programmed before the cycle call
