Programming technology functions (cycles)
8.4 Milling
Turning
436 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
CP
X0 or L0
Y0 or C0
Z0
(only ShopTurn)
Face Y: The positions refer to the reference point:
Positioning angle for machining area
Reference point X or reference point length polar
Reference point Y or reference point angle polar
Reference point Z
Degrees
mm
mm or
degrees
mm
Y0 or C0
Z0
X0
(only ShopTurn)
Peripheral surface C: The positions refer to the reference point:
Reference point Y or reference point angle polar – (only for single position)
Reference point Z
Cylinder diameter ∅
mm or
degrees
mm
mm
C0
Y0
Z0
X0
(only ShopTurn)
Peripheral surface Y: The positions refer to the reference point:
Positioning angle for machining surface – (only for single position)
Reference point Y
Reference point Z
Reference point X
Degrees
mm
mm
mm
Z1 Engraving depth (abs) or referenced depth (inc) mm
W Character height mm
DX1 or α2 Distance between characters or angle of opening – (for curved alignment only) mm or
Degrees
DX1 or DX2 Distance between characters or total width – (for linear alignment only) mm
α1 Text direction (for linear alignment only) Degrees
XM or LM
(only G code)
Center point X (abs) or center point length polar
– (for curved alignment only)
mm
YM or αM
(only G code)
Center point Y (abs) or center point angle polar
– (for curved alignment only)
mm
YM or CM
(only ShopTurn)
Center point Y or C (abs.) – (for curved alignment only)
- (only for machining surface, peripheral surface C/Y)
mm or
degrees
ZM
(only ShopTurn)
Center point Z (abs.) – (for curved alignment only)
- (only for machining surface, peripheral surface C/Y)
mm
