Programming technology functions (cycles)
8.6 Further cycles and functions
Turning
480 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Procedure
1. The part program or ShopTurn program to be processed has been
created and you are in the editor.
2. Select the "Miscellaneous" softkey.
3. Press the "Swivel plane" softkey.
The "Swivel plane" input window opens.
4. Press the "Basic setting" softkey if you wish to reestablish the initial
state, i.e. you wish to set the values back to 0.
This is done, for example, to swivel the coordinate system back to its
original orientation.
Parameters, G code program Parameters, ShopTurn program
PL
Machining plane T Tool name
D Cutting edge number
Feedrate mm/min
mm/rev
S / V
Spindle speed or constant
cutting rate
rpm
m/min
Parameters Description Unit
TC Name of swivel data set
Retract
- (only for G
code)
• No: No retraction before swiveling
• Z: Retraction in the direction of machine axis Z
• Z, X, Y: Move machining axis to retraction position before swiveling
• Tool direction, max.: Maximum retraction (up to the software end position) in the
tool direction
• Tool direction, inc.: Retraction, incremental (up to the software end position) in the
tool direction
When retracting in the tool direction, in the swiveled machine state, several axes
can move (travel).
ZR Retraction path - (only for incremental retraction in the tool direction) mm
Swivel plane
- (only for G
code)
• New: New swivel plane
• Additive: Additive swivel plane
RP - (only for
ShopTurn)
Retraction plane for face B
C0 - (only for
ShopTurn)
Position angle for machining surface Degrees
