Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
522 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
α1 Angular offset Degrees
Z1 Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
FR Reduced feedrate mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counterspindle stops at a defined distance away from transfer position Z1
and then traverses with a defined feedrate up to the fixed stop.
• No
The counterspindle traverses to the transfer position Z1.
Parameter Description Unit
Function, withdrawing
Also take zero point Also take zero point
• Yes
• No
Work offset Work offset in which the coordinate system offset by Z1 must be saved.
• Basic reference
• G54
• G55
• G56
• G57
• ...
Z1 Amount by which the workpiece is withdrawn from the main spindle (inc)
F Feedrate mm/min
Parameter Description Unit
Function, rear face
Work offset Work offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
• Basic reference
• G54
• G55
• G56
• G57
• ...
