Programming technology functions (cycles)
8.7 Additional cycles and functions in ShopTurn
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
523
Parameter Description Unit
Write to the work offset
• Yes
The Z value of the work offset can be directly written to the input screen form.
• No
The actual Z value of the work offset is used.
Z3W Machining position for special axis (abs.); machine coordinate system mm
ZV (abs) - only for work
offset. write "yes"
Offset Z=0. mm
ZV (inc) - only for work
offset. write "yes"
Workpiece zero is offset in Z direction (the sign is also evaluated) mm
Parameter Description Unit
Function, front face
Work offset Work offset for machining the next front face:
• Basic reference
• G54
• G55
• G56
• G57
• ...
Park counterspindle Traverse counterspindle to park position
• Yes
• No
Z3P - only for park
counterspindle "yes".
Counterspindle park position mm
