Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
551
Parameter Description Unit
XT Tool change point X ∅ mm
ZT Tool change point Z mm
S Spindle speed rev/min
Spindle chuck data
• Yes
You enter spindle chuck data in the program.
• No
Spindle chuck data are transferred from the setting data.
Note:
Please observe the machine manufacturer’s instructions.
Spindle chuck data
• Only chuck
You enter spindle chuck data in the program.
• Complete
You enter tailstock data in the program.
Note:
Please observe the machine manufacturer’s instructions.
Data for
• Main spindle
• Counterspindle
• Empty
If several spindles have been set-up, the program can operate at both
spindles.
Retraction The retraction area indicates the area outside of which collision-free traversing
of the axes must be possible.
• simple
• extended – not for a "pipe" blank
• all
XRA Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI - for "basic" retraction, only for a "pipe" blank
retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
ZRI Retraction plane Z rear – only for retraction "all" mm
Tailstock
• Yes
• No
XRR Retraction plane tailstock – only "Yes" for tailstock mm
