Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
550 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameter Description Unit
XA Outer diameter ∅ mm
Inner diameter ∅ (abs) or wall thickness (inc) mm
ZA Initial dimension mm
ZI Final dimension (abs) or final dimension in relation to ZA (inc) mm
ZB Machining dimension (abs) or machining dimension in relation to ZA (inc)
Retraction
The retraction area indicates the area outside of which collision-free traversing
of the axes must be possible.
• simple
XRA
Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI
- only for "pipe" blank
Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA
Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
• extended - not for a "pipe" blank
mm
XRA
Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
mm
XRI
Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA
Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
• all
mm
XRA
Retraction plane X external ∅ (abs) or
retraction plane X referred to XA (inc)
XRI
Retraction plane X internal ∅ (abs) or
retraction plane X referred to XI (inc)
mm
ZRA
Retraction plane Z front (abs) or
retraction plane Z referred to ZA (inc)
mm
ZRI
Retraction plant Z rear mm
Tailstock
• Yes
• No
XRR Retraction plane tailstock – only "Yes" for tailstock mm
Tool change point
Tool change point, which must be approached by the revolver with its zero point.
• WCS (Workpiece Coordinate System)
• MCS (Machine Coordinate System)
Notes
• The tool change point must be far enough outside the retraction area that it
is not possible for any tool to protrude into the retraction area while the
revolver is moving.
• Ensure that the tool change point is relative to the zero point of the revolver
and not the tool tip.
