Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
570 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters Description Unit
Function
You can select one of the following functions:
• Synchronizing
• Complete
• Gripping
• Withdrawing
• Rear face
• Front face
Synchronization function Synchronizes with the counterspindle in the other channel.
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching
in the park position and angular offset is only possible in the machine
coordinate system.
• Workpiece coordinate system
The park position is specified in the workpiece coordinate system.
XP Park position of tool in X direction (abs) mm
ZP Park position of tool in Z direction (abs) mm
Function, complete Gripping
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching
in the park position and angular offset is only possible in the machine
coordinate system.
• WCS
The park position is specified in the workpiece coordinate system.
XP Park position of tool in X direction (abs) mm
ZP Park position of tool in Z direction (abs) mm
Flush chuck Flush counterspindle chuck
• Yes
• No
DIR Direction of rotation
• Spindle rotates clockwise
•
Spindle rotates counter-clockwise
•
Spindle does not rotate
S Spindle speed – (only when the spindle rotates) rev/min
α1 Angular offset Degrees
Z1 Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
