Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
571
Parameters Description Unit
FR Reduced feedrate mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counterspindle stops at a defined distance away from transfer position
Z1 and then traverses with a defined feedrate up to the fixed stop.
• No
The counterspindle traverses to the transfer position Z1.
Function, complete Withdrawing
Withdraw blank Withdraw complete blank:
• Yes
• No
F Feedrate mm/min
Cutting-off
cycle
Cutting-off cycle in the following block
• Yes
• No
Function, complete Rear face
Zero offset Zero offset in which the coordinate system, which was shifted according to ZW
and by ZV as well as mirrored in Z, must be saved:
• Basic reference
• G54
• G55
• G56
• G57
• ...
ZW Machining position for special axis (abs.); machine coordinate system mm
ZV Offset Z = 0
Workpiece zero is offset in Z direction (inc, the sign is also evaluated)
mm
Parameters Description Unit
Function, gripping Teaching in the park position and angular offset is possible
Coordinate
system
• MCS
The park position is specified in the machine coordinate system. Teaching in
the park position and angular offset is only possible in the machine coordinate
system.
• WCS
The park position is specified in the workpiece coordinate system.
XP Park position of tool in X direction (abs) mm
ZP Park position of tool in Z direction (abs) mm
