Multi-channel machining (only 840D sl)
9.2 Multi-channel support (only 840D sl)
Turning
572 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Parameters Description Unit
Flush chuck Flush counterspindle chuck
• Yes
• No
DIR Direction of rotation
• Spindle rotates clockwise
•
Spindle rotates counter-clockwise
•
Spindle does not rotate
S Spindle speed – (only when the spindle rotates) rev/min
α1 Angular offset Degrees
Z1 Transfer position (abs.)
ZR Position, feedrate reduction (abs or inc)
Position from which a reduced feedrate is used.
FR Reduced feedrate mm/rev
Fixed
stop
Travel to fixed stop
• Yes
The counterspindle stops at a defined distance away from transfer position Z1
and then traverses with a defined feedrate up to the fixed stop.
• No
The counterspindle traverses to the transfer position Z1.
Parameters Description Unit
Function, withdrawing
Also take zero point Also take zero point
• Yes
• No
Zero offset Zero offset in which the coordinate system offset by Z1 must be saved.
• Basic reference
• G54
• G55
• G56
• G57
• ...
Z1 Amount by which the workpiece is withdrawn from the main spindle (inc)
F Feedrate mm/min
