Tool management
11.5 Tool list
Turning
592 Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
Icons in the tool list
Icon/
Marking
Meaning
Tool type
Red "X"
The tool is disabled.
Yellow triangle pointing
downward
The prewarning limit has been reached.
Yellow triangle pointing
upward
The tool is in a special state.
Place the cursor on the marked tool. A tool tip will
provide a brief description.
Green border
The tool is preselected.
Magazine/location number
Green double arrow
The magazine location is positioned at the change
position.
Gray double arrow
The magazine location is positioned at the loading
position.
Red "X"
The magazine location is disabled.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Tool list" softkey.
The "Tool List" window opens.
See also
Displaying tool details (Page 620)
Changing the cutting edge position or tool type (Page 622)
