Tool management
11.5 Tool list
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
591
Further parameters
If you have set up unique cutting edge numbers, these are displayed in the first column.
Column heading Meaning
D no. Unique cutting edge number
SN Cutting edge number
SC
Setup offsets
Display of the existing setup offsets
You use the configuration file to specify the selection of parameters in the list.
Software option
In order to be able to manage the parameter spindle direction of rotation,
coolant and tool-specific functions (M1-M4), you require the
"ShopMill/ShopTurn" option.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
References
Information on the configuration and setting up of the tool list can be found in the following
references:
Commissioning Manual SINUMERIK Operate (IM9) / SINUMERIK 840D sl
