Introduction
2.2 Operator panel fronts
Turning
30 Operating Manual, 01/2015, 6FC5398-8CP40-5BA2
<Cursor up>
•
Editing box
Moves the cursor into the next upper field.
•
Navigation
– Moves the cursor in a table to the next cell upwards.
– Moves the cursor upwards in a menu screen.
<Cursor up> + <CTRL>
•
Moves the cursor in a table to the beginning of the table.
•
Moves the cursor to the beginning of a window.
<Cursor up> + <SHIFT>
In the program manager and in the program editor, selects a
co
ntiguous selection of directories and program blocks.
<Cursor down>
•
Editing box
Moves the cursor downwards.
•
Navigation
– Moves the cursor in a table to the next cell downwards.
– Moves the cursor in a window downwards.
<Cursor down> + <CTRL>
•
Navigation
– Moves the cursor in a table to the end of the table.
– Moves the cursor to the end of a window.
•
Simulation
Reduces the override.
<Cursor down> + <SHIFT>
In the program manager and in the program editor, selects a
co
ntiguous selection of directories and program blocks.
<SELECT>
Switches between several specified options in selection lists
and in selection
boxes.
Activates checkboxes.
In the program editor and in the program manager, selects a
pr
ogram block or a program.
<SELECT> + <CTRL>
When selecting table rows, switches between selected and not
selected.
