Color Corrector Functions
Knob
Parameter
Adjustment
Setting values
1
Top
Top position
–100.00 to +100.00
2
Left
Left position
–100.00 to +100.00
3
Right
Right
position
–100.00 to +100.00
4
Bottom
Bottom
position
–100.00 to +100.00
5
Soft
Degree of
softness of
box
0.00 to 100.00
Knob
Parameter
Adjustment
Setting values
1
Size
Pattern size
0.00 to 100.00
2
Soft
Degree of
softness of
pattern edge
0.00 to 100.00
5
Pattern
Pattern
number
1 to 24
Knob
Parameter
Adjustment
Setting values
1
Size
Pattern size
0.00 to 100.00
2
Soft
Degree of
softness of
pattern edge
0.00 to 100.00
Chapter
9
Color
Corrector
Notes
When [Mask 2] is selected in the Secondary CCR
menu, linked to this setting it automatically changes
from [Mask 2] to [Mask 1].
3 Press [Mask1 Adjust].
The Mask1 Adjust menu appears.
4 In the <Mask Source> group, select the mask source.
Box: signal from dedicated box generator
Pattern: signal from dedicated pattern generator
5 Depending on the selection in step 3, adjust the
following parameters.
When Box is selected
When Pattern is selected
For the pattern selection, you can also press [Mask Ptn
Select] in the Mask1 Adjust menu, then use the Mask
Ptn Select menu.
Press any of the displayed patterns (standard wipe
patterns 1 to 24) to select it, then you can adjust the
following parameters.
6 When selecting the pattern as a mask source, set the
pattern modifiers as required.
When turning [Position] on and setting the pattern
position
Knob
Parameter
Adjustment
Setting values
1
Position H
Horizontal
position
–200.00 to +200.00
a)
2
Position V
Vertical
position
–200.00 to +200.00
a)
a) See “Setting the wipe position (Positioner)” (page 169).
When turning [Multi] on and replicating the same
pattern
Knob
Parameter
Adjustment
Setting values
1
H Multi
Number of
repetitions of
pattern
horizontally
1 to 63
2
V Multi
Number of
repetitions of
pattern
vertically
1 to 63
3
Invert Type
Replication
layout
1 to 4
a)
a) See “Setting the wipe pattern replication (Multi)” (page 171).
When turning [Aspect] on and setting the aspect
ratio of the pattern
Knob
Parameter
Adjustment
Setting values
1
Aspect
Aspect ratio
–100.00 to +100.00
a)
a) See “Setting the wipe pattern aspect ratio (Aspect ratio)” (page 171).
When turning the [Angle] on in the <Rotation>
group and slanting the pattern
Knob
Parameter
Adjustment
Setting values
1
Angle
Angle of
pattern
rotation
–100.00 to +100.00
a)
a) See “Angle” (page 170).
When turning [Speed] on in the <Rotation> group
and rotating the pattern at a fixed rate
Knob
Parameter
Adjustment
Setting values
1
Speed
Rotation
rate of
pattern
–100.00 to +100.00
a)
a) See “Speed” (page 170).
7 To invert the mask source, return to the Primary CCR
menu and press [Pri/Sec Mask Invrt], turning it on.
