Xerox Phaser 3610

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-264
4
• Execute the Diag Digital Input 071-102
to check the operation of the REGI-
SENSOR HVPS.
• Is the REGI-SENSOR HVPS operating
normally?
Go to Step 5.
Go to
FIP 2.03
5
• Execute the Diag Digital Input [071-119]
to check the operation of the Tray 2 Path
Sensor.
• Is the Tray 2 Path Sensor operating
normally?
Go to Step 6.
Go to
FIP 2.07
6
• Execute the Diag Digital Output 071-021
to check the operation of the Tray 2 TAKE
AWAY CLUTCH.
•Is the Tray 2 TAKE AWAY CLUTCH
operating normally?
Go to Step 7.
Go to
FIP 2.13
7
• Check the operation of the OPTIONAL
TRAY MOTOR-ASSEMBLY
• Execute the Diag Digital Output Tray 2:
[071-009] to check the rotation of the
OPTIONAL TRAY MOTOR-ASSEMBLY.
•Is it working properly?
Go to Step 8.
Go to
FIP 2.17
8
•Replace (REP 7.8 Feeder Assembly).
• Does an error occur?
Replace
(REP 5.6 MCU
PWB)
Troubleshooting
complete.
Step Check and Action Yes No
