Xerox Phaser 3610

Specifications
Phaser 3610, WorkCentre 3615 Service Manual 8-7
Space Requirements for the 3610
The printer requires the minimum installation space shown below for typical operation.
(Space occupied by the operator is not included.)
•Top View
• Right-side View
ZaS06002FA
400mm
393mm
100mm
110mm
893mm
600mm
426mm
400mm
FRONT
REAR
ZaS06006FA
FRONT
REAR
110mm
400mm
315mm
715mm
600mm
426mm
400mm
