Xerox Phaser 3610 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual5-62
Quick Reference Spares List for the 3610 and 3615
SFP/MFP Part Number Part Description PL Number REP Number
SFP
MFP
604K85880
604K85890
Front Cover Assembly
Front Cover Assembly
PL 1.1
PL 1.2
REP 1.2
SFP
MFP
848E82792
848E82815
Left Side Cover
Left Side Cover
PL 1.1
PL 1.2
REP 1.7
REP 1.11
SFP
MFP
604K84920
604K84931
Top Front Cover Assembly
Top Front Cover Assembly
PL 1.1
PL 1.2
REP 1.3
SFP
MFP
604K84941
848K68342
Right Side Cover
Right Side Cover
PL 1.1
PL 1.2
REP 1.6
REP 1.13
SFP
MFP
848K62885
848K62912
Top Cover Assembly
Top Cover Assembly
PL 1.1
PL 1.2
REP 1.4
REP 1.15
SFP
MFP
848K70060
604K85650
Rear Cover Assembly
Rear Cover Assembly
PL 1.1
PL 1.2
REP 1.5
REP 1.18
SFP
MFP
848E82672 Lower Rear Cover PL 1.1
PL 1.2
REP 1.8
REP 1.18
MFP 848E82901 IIT Lower Right Cover PL1.2 REP 1.13
MFP 848E89270 IIT Right Inner Cover PL 1.2 REP 1.14
MFP 848E89213 Upper Left Side Cover PL 1.2 REP 1.16
MFP 848E89231 Upper Right Side Cover PL 1.2 REP 1.13
SFP
MFP
604K77391
604K85900
Cover Extension Assembly
Cover Extension Assembly
PL 1.1
PL 1.2
REP 1.3
868E76893 Rear Strap PL 1.3 NA
SFP 848K79123 Control Panel PL 1.4 REP 1.1
MFP 848K75635
848K82824
Control Panel 110V
Control Panel 220V
PL 1.5 REP 1.12
MFP 848E93191 IIT Front Bottom Cover PL 1.5 REP 1.10
MFP 848E93181 IIT Front Top Cover PL 1.5 REP 1.9
MFP 848E93171 Lower Left Side Cover PL 1.5 REP 1.17
059K79334 Registration Transport Assembly PL 2.1 REP 2.2
803E13351 Tray 1 Stopper PL 2.1 REP 2.8

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
