Xerox Phaser 3610 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-63
SFP
MFP
604K85740
604K85750
Rear Interlock Assembly
Rear Interlock Assembly
PL 2.1 REP 2.10
121K51870 Registration Clutch PL 2.2 REP 2.6
059K74580 Rubber Roll Assembly PL 2.2 REP 2.7
055E60433 Registration Shutter Sensor PL 2.2 REP 2.8
604K11192 Feed Rolls (3 pack) PL 2.3 REP 2.4
121K51880 Feed Clutch PL 2.3 REP 2.5
054K48100 Duplex Chute Assembly PL 2.4 REP 2.1
604K77510 Exit Chute Left Pinch Roll Assembly PL 2.5 REP 2.12
604K77520 Exit Chute Right Pinch Roll Assembly PL 2.5 REP 2.12
930W00123 Exit Chute Full Stack Sensor PL 2.5 REP 2.13
054K48380 Exit Chute Assembly PL 2.5 REP 2.11
121E23570 MSI Feed Solenoid PL 2.6 REP 2.14
059K78790 MSI Pick Up Holder Assembly PL 2.6 REP 2.15
801K57914 MSI Top Frame Assembly PL 2.6 REP 2.16
050K71290 MSI Tray Assembly PL 2.7 NA
604K78370 MSI Retard Roll Assembly PL 2.7 REP 2.17
062K24263 ROS Assembly PL 3.2 REP 3.1
007K18413 Toner Dispense Drive Assembly PL 3.3 REP 4.6
127K52160 Toner Dispense Motor PL 3.3 REP 4.7
604K77290 CRUM Assembly PL 3.3 REP 3.2
116K91040 Xerographic Connector Assembly PL 3.3 REP 3.3
059K75560 Transfer Roll Assembly CRU PL 3.4 REP 3.4
126K30919
126K30929
Fusing Assembly 110v
Fusing Assembly 220v
PL 3.5 REP 3.5
007K18903 Main Drive Assembly PL 4.1 REP 4.1
007K18912 Drive Exit Out Holder Assembly PL 4.1 REP 4.2
007K18931 Drive Exit In Holder Assembly PL 4.1 REP 4.3
SFP/MFP Part Number Part Description PL Number REP Number

Xerox Phaser 3610 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	6.5 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Maximum duty cycle	110000 pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Network ready	Yes
Security algorithms	EAP, EAP-TLS, EAP-TTLS, WPA-PSK, WPA2-PSK
Mobile printing technologies	Apple AirPrint
Internal memory	512 MB
Processor frequency	400 MHz
Maximum internal memory	1024 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	56 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Maximum print size	216 x 356 mm
Paper tray media types	Card stock, Envelopes, Labels, Plain paper
Paper tray media weight	60 - 216 g/m²
ISO A-series sizes (A0...A9)	A4, A5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet
Optional connectivity	Wireless LAN
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 R2, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (standby)	52 W
Power consumption (printing)	686 W
Power consumption (PowerSave)	2 W
Sustainability certificates	ENERGY STAR
Operating temperature (T-T)	15 - 28 °C
Operating relative humidity (H-H)	20 - 70 %
Product color	Blue, White

Weight and Dimensions

Depth	426 mm
Width	393 mm
Height	315 mm
Weight	13000 g
